NEW DEVELOPMENT 2021 | #09 CUPRA FORMENTOR VZ, 4DRIVE, Type KM



Car and engine specification:

CUPRA FORMENTOR VZ, 4Drive, Type KM, 2020--> =>
2.0L TSI 228 KW (DNF, WITH GPF)

REMUS AXLE-BACK-SYSTEM L/R



  • 100% stainless steel
  • Powerful sound
  • Performance and torque increase
  • Light weight construction
  • Made in Austria

INFOBOX:

  • Axle-Back-System L/R: 040020 1500 + 790020 9999 + tail pipe set! The original exhaust must be cut!
  • OPF-Back-System L/R: 040020 0300 + 040020 1500 + 790020 9999 + tai pipe set! No vehicle modifications required!
  • RACING-OPF-Back-SystemL/R:040120 0300 (no EC type approval) + 040120 1500 (no EC type approval) + 790020 9999 + tail pipe set! No vehicle modifications required!

The use of racing products and products which do not have EC approval is generally not permitted on public roads

When fitting REMUS sports silencers, cat-back systems and cat replacement pipes designed for use on closed tracks, it is advantageous to carry out an ECU remapping, in order to exploit the optimum performance of the exhaust system and to prevent the check engine from lighting up.

Part. Nr. Description
040020 0300

Resonated front section (absorption principle)

Original tube Ø 60 mm - REMUS tube Ø 76 mm
incl. EC type approval

Connection to front parts at the manufacturer connection point. Installation/fitting at the serial mounting points. Including mounting material

040120 0300

Racing GPF-back front section replacement tube incl. resonator
Connection to front parts at the manufacturer connection point. Installation/fitting at the serial mounting points. Including mounting material

Original tube Ø 65 mm - REMUS tube Ø 76 mm
no EC type approval

040020 1500

Sport exhaust centered (absorption principle) for L/R system
incl. connection tube with spherical connection for mounting of the the sport exhaust. Installation/fitting at the serial mounting points. Can only be used in combination with set of outlet tubes 790020 9999 Including mounting material

Original tube Ø 70 mm - REMUS tubeØ 76 mm
incl. EC type approval

040120 1500

RACING sport exhaust centered (resonator) for L/R system
incl. connection tube with spherical connection for mounting of the the sport exhaust. Installation/fitting at the serial mounting points. Can only be used in combination with set of outlet tubes 790020 9999. Including mounting material

Original tube Ø 70 mm - REMUS tube Ø 76 mm
no EC type approval

790020 9999

Set of outlet tubes (quad flow) consisting of:
2 outer outlet tubes with integrated valves, 2 inner outlet tubes without valves. Including mounting material

Choose from following tail pipe package
0046 70SGR

stainless steel tail pipe set

4 tail pipes Ø 102 mm angled, straight cut, chromed, with adjustable spherical clamp connection

0046 70SR

stainless steel tail pipe set

4 tail pipes Ø 102 mm angled, chromed, with adjustable spherical clamp connection

0046 98CBR

stainless steel tail pipe set

4 tail pipes Ø 98 mm Street Race Black Chrome, with adjustable spherical clamp connection

0046 70CSR

carbo tail pipe set

4 Carbon tail pipes Ø 102 mm angled, Titanium internals, with adjustable spherical clamp connection

0046 70SSR

stainless steel tail pipe set

4 tail pipes Ø 102 mm angled/angled, chromed, with adjustable spherical clamp connection

0046 70CSSR

Carbon tail pipe set

4 carbon tail pipe sØ 102 mm angled/angled, Titanium internals, with adjustable spherical clamp connection

0046 98CR

stainless steel tail pipe set

4 tail pipes Ø 98 mm Street Race, with adjustable spherical clamp connection

DISCLAIMER

The products of REMUS Innovation GmbH („REMUS“) are distributed worldwide. REMUS and its affiliates shall not assume any obligations, warranties, guarantees or other liabilities for the fact that the products manufactured by REMUS comply with the applicable law of the respective country of destination or may be used without (official) approval. This applies equally to products approved in Austria, which are subsequently manipulated, modified, edited or otherwise interfered or changed by the respective buyer, so that it no longer has its original condition.

The buyer shall be solely responsible for obtaining all whatsoever approvals and permissions required by the respective national law for suchlike products and shall be solely responsible for ensuring that the products manufactured by REMUS comply with the approvals required for the respective usage in the country of destination.

Intended use in Austria:
Products manufactured by REMUS without (EC-)approval are only eligible for usage at motor sport events or tests within the meaning of KFG 1967. They are not intended for vehicles used on public roads. The buyer is solely responsible for obtaining the permissions where applicable required by the applicable law for the intended purposes/usage. In no event a whatsoever claim shall be constituted by the buyer against REMUS and its affiliates arising from or in connection with required approvals for public road usage.
